型号Model | 压力 Pressure | 排气量 Airflow | 功率 Power | 外形尺寸 Dimensions | 重量 Weight |
Bar | M3/min | KW | L*W* H(mm) | Kg |
BNS-55WG-7A(W) | 7 | 8.8/9.6 | 55 | 2160*1450*2200 / 2180*1450*2200 | 1900/2000 |
BNS-55WG-8A(W) | 8 | 8.0/7.8 | 55 | 2160*1450*2200/ 2180*1450*2200 | 1900/2000 |
BNS-55WG-10A(W) | 10 | 7.3/7.4 | 55 | 2160*1450*2200 / 2180*1450*2200 | 1900/2000 |
BNS-75WG-7A(W) | 7 | 12.1/12.3 | 75 | 2160*1450*2200 / 2180*1450*2200 | 1900/2100 |
BNS-75WG-8A(W) | 8 | 11.1/11.6 | 75 | 2160*1450*2200 / 2180*1450*2200 | 1900/2100 |
BNS-75WG-10A(W) | 10 | 10.8/10.7 | 75 | 2160*1450*2200 / 2180*1450*2200 | 1900/2100 |
BNS-90WG-7A(W) | 7 | 14.3/14.5 | 90 | 2160*1450*2200 / 2180*1450*2200 | 2000/2100 |
BNS-90WG-8A(W) | 8 | 13.6/13.5 | 90 | 2160*1450*2200 / 2180*1450*2200 | 2000/2100 |
BNS-90WG-10A(W) | 10 | 12.7/13.0 | 90 | 2160*1450*2200 / 2180*1450*2200 | 2000/2100 |
BNS-110WG-7A(W) | 7 | 18.5/19.1 | 110 | 4050*1650*2000/ 2550*1650*2000 | 3700/2700 |
BNS-110WG-8A(W) | 8 | 17.2/17.1 | 110 | 4050*1650*2000/ 2550*1650*2000 | 3700/2700 |
BNS-110WG-10A(W) | 10 | 16.1/16.2 | 110 | 4050*1650*2000 / 2550*1650*2000 | 3700/2700 |
BNS-132WG-7A(W) | 7 | 21.8/22.0 | 132 | 4050*1650*2000/2550*1650*2000 | 3700/2800 |
BNS-132WG-8A(W) | 8 | 19.5/19.9 | 132 | 4050*1650*2000/2550*1650*2000 | 3700/2800 |
BNS-132WG-10A(W) | 10 | 19.0/19.2 | 132 | 4050*1650*2000/2550*1650*2000 | 3700/2800 |
BNS-145WG-7A(W) | 7 | 23.3/23.6 | 145 | 4050*1650*2000 / 2550*1650*2000 | 3800/2900 |
BNS-145WG-8A(W) | 8 | 21.7/21.8 | 145 | 4050*1650*2000 / 2550*1650*2000 | 3800/2900 |
BNS-145WG-10A(W) | 10 | 20.1/20.3 | 145 | 4050*1650*2000/ 2550*1650*2000 | 3800/2900 |
BNS-160WG-7A(W) | 7 | 28.0/28.5 | 160 | 5040*1650*2100 / 3100*1650*2000 | 5300/3900 |
BNS-160WG-8A(W) | 8 | 25.8/26.4 | 160 | 5040*1650*2100/3100*1650*2000 | 5300/3900 |
BNS-160WG-10A(W) | 10 | 24.0/24.5 | 160 | 5040*1650*2100 / 3100*1650*2000 | 5300/3900 |
BNS-200WG-7A(W) | 7 | 34.1/36.1 | 200 | 5040*1650*2100 / 3100*1650*2000 | 5400/4000 |
BNS-200WG-8A(W) | 8 | 31.3/33.1 | 200 | 5040*1650*2100 /3100*1650*2000 | 5400/4000 |
BNS-200WG-10A(W) | 10 | 30.2/30.8 | 200 | 5040*1650*2100/3100*1650*2000 | 5400/4000 |
BNS-250WG-7A(W) | 7 | 42.5/43.3 | 250 | 5040*1650*2100/3100*1650*2000 | 5500/4100 |
BNS-250WG-8A(W) | 8 | 40.5/41.2 | 250 | 5040*1650*2100/3100*1650*2000 | 5500/4100 |
BNS-250WG-10A(W) | 10 | 36.8/38.0 | 250 | 5040*1650*2100/3100*1650*2000 | 5500/4100 |
BNS-275WG-7A(W) | 7 | 44.6/46.5 | 275 | 5040*1650*2100/3100*1650*2000 | 5500/4200 |
BNS-275WG-8A(W) | 8 | 42.5/43.2 | 275 | 5040*1650*2100 / 3100*1650*2000 | 5500/4200 |
BNS-275WG-10A(W) | 10 | 40.5/41.3 | 275 | 5040*1650*2100 / 3100*1650*2000 | 5500/4200 |
